NuPrime CDP-9
$ 1,595.00
The NuPrime CDP-9 is a highly accurate CD player with an integrated high-end DAC and preamp. A powerful DSP-based decoder that provides all Red Book error-correction capabilities with master-clock control of the entire decoding system, thus lowering jitter significantly. The transport’s single speed minimizes vibration and unbalanced discs. The high-performance DAC, together with a selectable sampling rate converter for the digital output (up to 32bit/768kHz and DSD512) converts the CD format to either SPDIF at highest sampling rate or DSD format up to DSD512.
Features:
Highly Accurate CD Playback
- A powerful ARM chip LPC2103F CD reads, writes and controls error correction
- Philips SAA7824HL high-end laser reads/writes head control and decodes chips for CD transport.
- Supports CD-DA CD-R, CD-RW
- Algorithm reduces digital interference and jitter
Sampling Rate Converter
- The sampling rate of any digital inputs, including CD playback, can be converted up or down between PCM and DSD, from 44.1kHz to 768kHz or DSD64 to DSD512
- The conversion is achieved by up-sampling to mega hertz before down converting to the targeted sampling rate with ultra-low jitter and distortion
Headphone Amp
- High performance op-amp headphone amp
Compatible OS
- Exclusive driver software for Windows
- Standard driver software for Mac
Power and Mechanical
- Low power consumption in Standby Mode
- Available in black or silver anodized aluminum finish
Inputs:
- COA: Coaxial input for CD/DVD/BD players, TV and any device with a coaxial source.
- OPT: Optical input for CD/DVD/BD players, TV and any device with an optical source.
- USB: USB input for computer (PC/MAC) and for NAS devices. CDP-9 does not guarantee that all NAS will operate and be compatible due to wide variety of brands and custom specs.
- EXT: Extension (digital) port * for optional Bluetooth and WiFi module.
- AES: AES balance input.
Outputs:
- Optical Output (up to 24 bits / 192 kHz) (DoP64)
- Coaxial Output (up to 24 bits / 768KHz) (DoP256)
- I2S Output (up to 24 bits / 768KHz) (DoP512)
- ANALOG OUT: Stereo RCA Output (4Vrms)
- XLR Balance OUT: True balance XLR balance Output (8Vrms)
Note that the I2S output is for connecting to other NuPrime products and may not work with other devices.
SPECIFICATIONS
- USB Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96KHz,176.4KHz,192KHz, 352.8KHz, 384KHz, 768KHz and DSD 2.8MHz(64), 5.6MHz(128), 11.3MHz(256), 22.6MHz(512)
- Coaxial Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96KHz,176.4KHz, 192KHz, 352.8KHZ, 384KHz, 705KHz, 768KHz, Dop64, Dop128, Dop256
- Optical Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz, 192KHz, Dop64
- Bit Resolution: 16-32-bits
- D/A THD+N: 0.0005%
- D/A SNR > 120 dB
- Frequency Response: 10Hz to 20KHz ± 0.3dB
- CD THD+N: 0.003%
- CD SNR > 114 dB
- Headphone output power: 150 mW @ 1 kHz and 33 ohm load
- Dimensions: 235 mm W x 281 mm D x 55 mm H (including feet)
- Weight: 2.3Kg
- Worldwide AC voltage: 100VAC~240VAC Adapter
Power Consumption
- 100V (115V)
- Standby consumption: 1.9W
- Power On Idle: 7.6W
- CD Playback: 10.2W
- 230V
- Standby consumption: 2.7W
- Power On Idle: 8.3W
CD Playback: 11.3W
* DC power input: 12 to 15V (NuPrime LPS 212 is suitable for CDP-9)
“For just over $1700 the NuPrime CDP-9 delivers extremely competently over a very wide range of feature sets. Primarily, people will see this as a CD Player and certainly compared to my old flagship Meridian it competes very well indeed with additional detail and a very accurate yet decidedly “not” sterile in sound quality.
However, there is much more to it than that. The big attraction for me is the DAC features with both analog and digital inputs and outputs as well as the bonus feature of a being able to drive efficient IEMs and headphones from a headphone amp. The hybrid volume control and opamp design of the CDP-9 will deliver excellent channel balance and a very black background with next to no noise.
For those coming from similar modern Sabre DAC infused DACs such as the Sonica from Oppo you will find that the CDP-9 is just that bit livelier and more engaging. This is a clean sound but an energetic and 3-dimensional performance.”
-> Read more about this exceptionally detailed review by Marcus, Headfonics.com
(also included in the review are comparisons with Oppo Sonica, Hugo 2, Cayin iDAC-6)
“The NuPrime CDP-9 clearly better than any CD Playing system we have sold previously over the last decade with the exception of the top end Meridian products. And even then it does bring something unique to the party. The CDP-9 is also better than our previous recommendations of transport (Oppo and Cambridge) and DAC combinations, both in performance and value for money. The quality and implementation of the new Sabre chipset surpass the digital performance of both NuPrime’s own IDA-8 and DAC-9.
There is also a certain irony going on here with the cycling of formats. CD was predicted to spell the end of vinyl and that’s come back. Streaming was supposed to spell the end of CD (and let’s not even start to talk about format changes with the little silver discs). But here we are with a new player from a forward looking company that breathes new life into the compact disc. If you have a CD collection, NuPrime are looking after you.”
-> Read more about CDP-9 from John Ransley at Totallywired.nz
